* Incluye Pato Lubricador + Freno
El taladro de roca Stopper YSP45 se utiliza para la perforación de roca, los agujeros de voladura y otros trabajos drilling en las minas, las minas de pequeño carbón y otras construcciones. Es conveniente para la perforación de agujeros horizontales o inclinados en tipos de roca semidura y dura.
| Peso | 26kg | Torque | ≥23N*m |
| Longitud | 661mm | Velocidad de perforación | ≥470Mm/min |
| Ø del cilindro | 80mm | Ruido | ≤124DB |
| Carrera del pistón | 60mm | Ø interior manguera de aire | 25mm |
| Presión de trabajo | 0.4Mpa | Ø interior manguera de agua | 13mm |
| Energía de impacto | ≥44J | Ø de perforación | 34-42mm |
| Frecuencia De impacto | ≥36HZ | Tamaño del mango | H22x108mm |
| Consumo de aire | ≤58L/s |
| N° | Código | Descripción |
|---|---|---|
| 1 | YSP45-201 | Front Head |
| 2 | YSP45-202A | Rotation sleeve |
| 3 | YSP45-204A | Steel sleeve |
| 4 | YSP45-203A | Rotation nut |
| 5 | YSP45-106 | Silencer |
| 6 | YSP45-109A | Cylinder |
| 7 | YSP45-111A | 2nd-Cylinder |
| 8 | YSP45-104 | Valve sleeve |
| 9 | YSP45-103 | Valve |
| 10 | YSP45-101 | Ratchet |
| 11 | YT30-3.06 | Small seal |
| 12 | YSP45-301A | Back head |
| 13 | YSP45-305 | Air tube |
| 14 | YSP45-306 | Water tube |
| 15 | 28.83-25 | O-ring seal |
| 16 | YSP45-407A | YXSea |
| 17 | YSP45-401 | Pipe connect |
| 18 | YSP45-402 | Buttom tray |
| 19 | YSP45-403 | Guide sleeve |
| 20 | YSP45-404 | Dustproof sleeve |
| 21 | GB93 22 | Spring washer |
| 22 | FT140-9 | Top fork |
| 23 | 0145-04-15A | Top tip |
| 24 | YSP45-405A | Telescopic pipe |
| 25 | YSP45-406A | Support ring |
| 26 | FT160A-7 | Paddy ring |
| 27 | YSP45-309A | Water tube nut |
| 28 | GB71 M8*10 | Fastening screw |
| 29 | FY500-8 | O-ring seal |
| 30 | YSP45-310 | Water tube sleeve |
| 31 | YSP45-311 | Air tube pad |
| 32 | YT25-3.14 | Air tube washer |
| 33 | YSP45-102 | Valve disk |
| 34 | 7655-111 | Screw nut |
| 35 | YSP45-107 | Screw bar |
| 36 | YSP45-108 | Piston |
| 37 | YSP45-110A | Guide sleeve assembly |
| 38 | YSP45-317 | Big rubber pad |
| 39 | 62-25 | O-ring seal |
| 40 | YSP45-318 | Water valve |
| 41 | 20*3-25 | O-ring seal |
| 42 | YSP45-319 | Rubber pad |
| 43 | YSP45-322 | Aluminum stopper |
| 44 | YSP45-320 | Water pipe connect |
| 45 | YSP45-321 | Screw nut |
| 46 | YSP45-314 | Water valve spring |
| 47 | YSP45-307 | Water valve inner |
| 48 | YSP45-302 | Operation valve |
| 49 | YSP45-303 | Stuck ring |
| 50 | YSP45-304 | Air pipe screw nut |
| 51 | 423-25 | O-ring seal |
| 52 | 34*3-25 | O-ring seal |
| 53 | YT25-3.20 | Spring |
| 54 | YT25-3.21 | Fixing pins |
| 55 | 7655-320A | Swell ring |
| 56 | 18*3-25 | O-ring seal |
| 57 | GB879 6*40 | Elastic conicall pin |
| 58 | YSP45-315A | Regulator |
| 59 | YT25-3.17A | Locating pin |
| 60 | GB6172 MIO | Hex thin nut |
| 61 | GB9310 | Spring washer |
| 62 | YSP45-316 | Operation handle |
| 63 | GB6171M20*1.5 | I-Hex nut |
| 64 | YSP45-308 | Long screw bar |
| 65 | GB56 M16 | Hex thick nut |
| 66 | 0145-01-22 | Handle |
| 67 | 014501-16 | Deflation valve |
| 68 | 223-25 | O-ring seal |
| 69 | 0145-01-15 | Deflation valve spring |
| 70 | 0145-01-13A | Deflation valve inner |
| 71 | 0145-01-14 | Deflation valve button |
| 72 | YSP45-105 | Fixing pins |
| 73 | YT25-1.15 | Tower spring |
| 74 | YT25-1.14 | Ratchel pawl |
| 75 | YSP45-312 | Air pipe elbow |
| 76 | YSP45-313 | Connection nut |
| 77 | 25-abr | Cone rubber connect |
| 78 | 25-ene | Butterfly nut |
| 79 | NO.2A | Hoop |
| 80 | YSP45-411 | Screw bolt |
| 81 | GB6170 M12 | I-Hexnut |
| 82 | GB9312 | Elastic washer |
| 83 | YSP45-500 | Water valve connect |
